Atek OLC 43X Optical Linear Encoder With Roller Guide
Save Product Save Product
Call for Pricing
Incremental optical system
Different mesuring lengths from 50 mm to 1000 mm
Selectable reference signal at every 10 mm
5µm resolution
IP54 protection class
60 m/min traversing speed
Compatible with Delem, Cybelec and ESA
Did you like this product? Add to favorites now and follow the product.
Save Product Save Product
Have a Question? Ask a Specialist
1800 2 ION TG Call Us
Description
| Measuring Type | Optical, transmissive |
|---|---|
| Measuring Lengths | Different measuring lengths from 50 mm to 1000 mm |
| Resolution | 5µm |
| Signal Period | 20 µm |
| Accuracy | ± 10 µm |
| Repeatability | ± 1 pulse |
| Max Traversing Speed | 60m/min |
| Supply Voltage | 5 VDC, 10…30 VDC |
| Çalışma Sıcaklığı | Current Consumption |
| Output Type | TTL, Push Pull Line Driver, NPN or PNP |
| Output Signals | A,B,Z A,B A,/A,B,/B A,/A,B,/B,Z,/Z |
| Reference Signal | At the beginning, middle or end of the measuring length, or selectable with magnet every 10 mm |
| Body Material | Aluminium |
Additional information
| Brand | Atek |
|---|---|
| Output | PNP, Push-Pull / TTL |
