GMT MSG-156E

Description

Display Type : 15.6TFT

Resolution : 1920 x 1080

Colour : 16.77M

Backlight : LED

Brightness : 250cd / m²

Backlight Life : >20.000 hours

Touch screen : 4-wire precision resistor circuit

Processor ​​ : Quad-Core 1.8 GHz Processor

Memory :4 GB Flash Memory + 512 MB Memory

RTC : Yes

Expansion Memory : 1 USB Hosts

Printer port : USB Slave (Pictbridge) / USB Host

Ethernet                                : Yes

Program Installation : Micro USB / RS-232 / Ethernet

COM Port: COM0: RS-232, RS-485, RS-422, COM2:RS-232

Power consumption : 15w

Operating voltage : 24VDC

Input Range : 18VDC – 28VDC

Momentary Power Outage : <3ms

Scale Insulation Resistance: >50MΩ (500VDC)

Dielectric Strength Test: 500VAC 1 minute

Case Material : Metal

Dimensions (mm): 395 x 259 x 25.5

Panel Slot Dimension (mm): 381.5 x 245.5

Weight (kg): 2.5

Operating temperature : 0 to 50°C

Working Environment Humidity: 10%rH to 90%rH, without condensation

Storage Temperature : -20 to 60°C

Storage Humidity: 10%rH to 90%rH, without condensation

Cooling Method: air cooling

Protection Class: IP65 (front panel)

Standards : CE marked, EN IEC 61000-6-4:2019, EN IEC 61000-6-2:2019
